Product Overview
Feeds video source to 8 HDMI displays
Supports 4K HDMI signals up to 18Gbps with HDR, HDCP 2.2, and surround audio up to Dolby® 7.1, Atmos / DTS-HD
Repairs HDMI signals for integration with long HDMI cables
HDMI Signal Distribution
1 HDMI Source to 8 HDMI Displays.
Ultra HD/4K Resolution
4096x2160 or 3840x2160 30Hz at 4:4:4 and 60Hz at 4:4:4.
18 Gbps Bandwidth
High Speed / Performance for latest HDMI standards.
Resolution Support
SD, HD, and VESA up to UHD/4K.
Surround Audio Support
Dolby® TrueHD, Dolby® Digital Plus, DTS-HD Master Audio™ and Dolby® Atmos.
HDMI Licensing
Fully licensed and compatible with HDMI.
HDCP Licensing
Compliancy up to HDCP 2.2 and backward compliant.
HDR10 (High Dynamic Range)
More life-like images through a greater range of luminance levels.
3D Ready
Capability to pass 3D stereoscopic signal formats.
Deep Color Support
Up to UHD/4K 30Hz 4:4:4/12 bits or 60Hz 4:4:4/8 bit.
EDID Control
Internal library with 15 EDID handshakes in addition to native EDID data of output/display.
Full Buffer™ System
Manages TMDS re-clocking / signal re-generation, HDCP source & display authentication, Hot Plug Management and EDID Control handshake.
Deep Color Support
Up to 12 Bit at UHD/4K 24/25/30Hz 4:4:4.
I2C Communication
EDID and HDCP buffering from Display to Source.
CEC Disconnect
Prevents all device communication signals via CEC, ARC, and HDMI Ethernet channels.
