General Specs |
| Color | Black |
| Depth (in.) | 20.75 |
| Width (in.) | 28.5 |
| Height (in.) | 24 |
| Fuel Type | Wood Logs |
| Outdoor Approved | No |
| Fireplace Type | Insert |
| Vent Location | Top |
| Collection | Inspire 2000 |
| Color Finish Name | Black |
Appliance Performance |
| Overall firebox volume-ft³ : | 2.4 |
| EPA loading volume-ft³ : | 1.95 |
| Maximum burn time : | 8 h |
| Overall heat output rate: | 14,200 BTU/h (4.16 kW) to 44,500 BTU/h (13.04 kW) |
| Average overall efficiency (dry cordwood) | 72 % (HHV), 77 % (LHV) |
| Optimum overall efficiency : | 79 % |
| Optimum heat transfer efficiency : | 76 % |
| Average particulate emissions rate : | 2.3 g/h |
| Average CO : | 69 g/h |
General Features |
| Combustion technology | Non-catalytic |
| High-efficiency certified appliance | Yes, EPA 2020 approved |
| Maximum log length | 20" |
| Log positioning | Loading over width |
| Chimney diameter | 6" |
| Type of chimney | Liner - ULC-S635, CAN/ULC-S640, UL1777 |
| Minimum chimney height (feet) | 12' |
| Baffle type | C-Cast or equivalent |
| Approved for a mobile home installation | No |
| Door type | Single, glass with cast iron frame |
| Glass type | Ceramic glass |
| Glass surface – dimensions (Width X Height) | 20.25" X 9.5" |
| Glass air-wash system | Yes |
| Premium quality blower included (CFM) | 176 |
| Door opening – dimension (Height) | 8.25" |
| Door opening - dimension (Width) | 20" |
| Firebox – dimension (Height) | 11.75" |
| Firebox – dimension (Width) | 21" |
| Firebox – dimension (Depth) | 16.75" |
| Moulded refractory bricks | Yes |
| Stainless-steel secondary-air system improving gas combustion | Yes |
| Steel thickness – body | 0.18" |
| Steel thickness – top | 0.38" |
| Fireplace opening – minimum (Height) | 24.62" |
| Fireplace opening – minimum (Width) | 29" |
| Fireplace opening – minimum (Depth) | 20 3/4" |
| USA standard (emissions) | EPA Method 28 |
| Canadian Standard (emissions) | CSA B415.1-10 |
| USA standard (safety) | UL 1482, UL 737 |
| Canadian standard (safety) | ULC S628 |
| Tested and listed as per applicable standards | By an accredited laboratory (CAN/USA) |
| Warranty | Limited lifetime |
