General Specs |
| Color | Black |
| Depth (in.) | 29.75 |
| Width (in.) | 36.75 |
| Height (in.) | 40.62 |
| Fuel Type | Wood Logs |
| Outdoor Approved | No |
| Fireplace Type | Wall Mounted |
| Vent Location | Top |
| Collection | Stratford II |
| Color Finish Name | Black |
Appliance Performance |
| Overall firebox volume-ft³ : | 2.5 |
| EPA loading volume-ft³ : | 1.94 |
| Maximum burn time : | 8 h |
| Overall heat output rate: | 12,700 BTU/h (3.72 kW) to 60,700 BTU/h (17.79 kW) |
| Average overall efficiency (dry cordwood) | 64% (HHV), 68% (LHV) |
| Optimum overall efficiency : | 70% |
| Optimum heat transfer efficiency : | 68% |
| Average particulate emissions rate : | 1.2 g/h |
| Average CO : | 98 g/h |
General Features |
| Combustion technology | Non-catalytic |
| High-efficiency certified appliance | Yes, EPA 2020 approved |
| Maximum log length | 20" |
| Log positioning | Loading over width |
| Chimney diameter | 6" |
| Flue outlet diameter | 6" |
| Type of chimney | CAN/ULC S629, UL 103 HT (2100 °F) |
| Minimum chimney height (feet) | 15' |
| Baffle type | C-Cast or equivalent |
| Approved for a mobile home installation | No |
| Door type | Double, glass with cast iron frame |
| Glass type | Ceramic glass |
| Glass surface – dimensions (Width X Height) | 22.25" x 12.5" |
| Glass air-wash system | Yes |
| Premium quality blower included (CFM) | 176 |
| Door opening – dimension (Height) | 10.25" |
| Door opening - dimension (Width) | 25.37'' |
| Firebox – dimension (Height) | 12.12" |
| Firebox – dimension (Width) | 20.37" |
| Firebox – dimension (Depth) | 12.87" |
| Moulded refractory bricks | Yes |
| Stainless-steel secondary-air system improving gas combustion | Yes |
| Cast iron andirons | Yes |
| USA standard (emissions) | EPA |
| Canadian Standard (emissions) | CSA B415.1-10 |
| USA standard (safety) | UL 127 |
| Canadian standard (safety) | ULC-S610 |
| Tested and listed as per applicable standards | By an accredited laboratory (CAN/USA) |
| Warranty | Limited lifetime |
