Valcourt Mundo II Black Wood Fireplace

Valcourt

Model #:

FP12R

Model #: FP12R
1317197
Valcourt
$99,999.00

At a Glance

Product Dimensions 40.6"h x 50.3"w x 27"d

Holder of industrial design protection, with its sleek lines and refined look, the Mundo II completely redefines the true nature of wood heating. Its modern design perfectly combines functionality, comfort, and safety. Environmentally friendly, this non-catalytic fireplace is EPA certified with an incredibly low particle emissions rate.Read More

Call for Best Price

Request More Info

Get to know this product.

Product Overview

Product Overview

The air gravity kit available with the Mundo II will allow you to harness all the power from this incredible fireplace while respecting the contemporary lines of your decor. The most serious user can also install a forced air kit which will allow for better and more efficient heat transfers to rooms located further from the fireplace.

Shown in traditional gravity kit

Made in Canada

Connect with your local dealer to see options and actual samples.

SBI is a Canadian family-owned business that designs, builds and markets residential heating products that are sold throughout the world.

*Any installation must be done according to the data and drawings detailed in the owner’s manual.

*Wood fireplace only, all other products are sold separately. Images may not reflect the actual size. Color in images may differ in person; see the local dealer for the actual finish.

Useful Documents
Dimensions
Quick Installation Reference Guide
Installation And Operation Manual
Specifications

General Specs

ColorBlack
Depth (in.)27
Width (in.)50.3
Height (in.)40.6
Fuel TypeWood Logs
Outdoor ApprovedNo
Fireplace TypeWall Mounted
CollectionMundo II
Manufacturer WarrantyLimited Lifetime
Color Finish NameBlack
BTU Heat Rating80000

Additional Information

Fuel typeDry cordwood (16" recommended)
Recommended heating area-ft² 750 - 2,200
Overall firebox volume-ft³ 2.5
EPA loading volume-ft³ 1.94
Maximum burn time 8 h
Maximum heat output-dry cordwood 80,000 BTU/h (23.4 kW)
Overall heat output rate <:12,700 BTU/h (3.72 kW) to 60,700 BTU/h (17.79 kW)
Average overall efficiency (dry cordwood)64% (HHV) (4) 68% (LHV) (5)
Optimum overall efficiency70%
Optimum heat transfer efficiency68%
Average particulate emissions rate 1.2 g/h
Average CO98 g/h
Combustion technology Non-catalytic
High-efficiency certified appliance Yes, EPA 2020 approved
Maximum log length 20"
Log positioning Loading over width
Chimney diameter 6"
Flue outlet diameter 6"
Type of chimney CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height (feet) 15'
Baffle type C-Cast or equivalent
Approved for a mobile home installation No
Door type Single, glass with steel frame
Glass type Ceramic glass
Glass surface – dimensions (Width X Height) 26.1" x 13.4"
Glass air-wash system Yes
Door opening – dimension (Height) 10.4"
Door opening - dimension (Width) 25.4"
Firebox – dimension (Height) 12.1"
Firebox – dimension (Width) 20.4"
Firebox – dimension (Depth) 12.9''
Moulded refractory bricks Yes
Stainless-steel secondary-air system improving gas combustion Yes
USA standard (emissions) EPA
Canadian Standard (emissions) CSA B415.1-10
USA standard (safety) UL 127
Canadian standard (safety) ULC-S610
Tested and listed as per applicable standards By an accredited laboratory (CAN/USA)
WarningProposition 65 Warning for California Residents
